ADS131E06 Replacement: GX131E06 Pin-to-Pin 6-Channel 24-Bit ADC

GX131E06 is developed for industrial power monitoring, protection, test and measurement, and simultaneous-sampling data acquisition systems.

Its six high-impedance input channels can interface with resistor-divider networks or voltage transformers for line-voltage measurement and with current transformers or Rogowski coils for current measurement.

The QFP64 version is designed for pin-to-pin hardware replacement of ADS131E06, allowing the existing QFP64 PCB footprint and pin routing to be retained. An optional BGA64 package is available for new designs requiring a smaller board footprint.

GX131E06 as a Pin-to-Pin ADS131E06 Replacement

GX131E06 integrates six simultaneous-sampling 24-bit delta-sigma ADC channels with programmable gain amplifiers, an internal voltage reference and an onboard oscillator.

The device supports output data rates from 250 SPS to 64 kSPS and programmable gains of 1, 2, 3, 4, 6, 8, 12 and 24. The additional low-data-rate and gain settings provide greater flexibility for measuring signals with different amplitudes and bandwidth requirements.

For existing ADS131E06-based equipment, the GX131E06 QFP64 package provides a pin-to-pin hardware migration path without redesigning the PCB footprint. GX131E06 is also suitable for new multichannel measurement and protection systems.

Pin-to-Pin QFP64 Hardware Compatibility and SPI Interface

The GX131E06 QFP64 version is designed around the ADS131E06 pin configuration. Existing analog-input connections, power connections, reference circuitry, clock and synchronization signals, GPIO connections and SPI signal routing can be retained.

The SPI interface supports communication with MCUs, DSPs and FPGAs. Four GPIO pins, synchronization control and daisy-chain operation simplify the implementation of multi-device systems requiring additional measurement channels.

The 8 mm × 8 mm BGA64 package provides the same six-channel conversion architecture in a smaller package for space-constrained new designs.

GX131E06 vs ADS131E06: Key Specification Comparison

GX131E06 retains the principal channel count, resolution, maximum data rate, supply ranges and system-control functions of ADS131E06 while providing additional gain settings, a 250 SPS operating mode and improved specified dynamic performance.

Measurement, Monitoring and System Features

Key GX131E06 features include:

l Six simultaneous-sampling 24-bit delta-sigma ADC channels

l Output data rates from 250 SPS to 64 kSPS

l Programmable gains of 1, 2, 3, 4, 6, 8, 12 and 24

l Dynamic range up to 120 dB at 1 kSPS

l −125 dB crosstalk

l −108 dB THD at 50 Hz and 60 Hz

l High-impedance analog inputs

l Flexible input multiplexer on each channel

l Internal test and temperature-monitoring signals

l Integrated comparators with DAC-programmable thresholds

l Input out-of-range and fault detection

l Integrated voltage reference and onboard oscillator

l SPI data interface

l Four GPIO pins

l Synchronization and daisy-chain operation

l QFP64 and compact BGA64 package options

l −40°C to +105°C operating-temperature range

GX131E06 Applications

GX131E06 is suitable for:

l Circuit-breaker and relay-protection equipment

l Single-phase and multiphase energy metering

l Power-quality monitoring systems

l Line-voltage and line-current measurement

l Battery test systems

l Industrial test and measurement equipment

l Simultaneous-sampling data acquisition systems

l Multichannel monitoring and protection equipment

Request the GX131E06 Datasheet, Samples and Technical Support

GXSC can provide the GX131E06 datasheet, QFP64 pinout information, samples, quotation and technical support for ADS131E06 replacement projects and new multichannel data acquisition designs.

Contact GXSC with your ADS131E06 ordering code, package requirement, power-supply configuration, sampling rate and application information to obtain product-selection and replacement support.
